Details & description

Voltage 14, Amp 36, Pulley w/o, Prod. info BN/OE, Bracket Hole Size Rear 8.20, D+ Position 20, Servicing Ford, Land Rover, Triumph, Vauxhall, Lotus, Jaguar, Mercury, Source Lucas, Mounting Bracket Distance 88.00, Radius 81.00, Belt Adjustment Bracket Hole 1 8.20, Regulator type IR, Bracket Hole Size 1 8.20, D+ Size 6.30, Holder Arm Width 9.70, B+ 9.40, Radius 2 83.00, Plug no. 1 PL22, Rotation CW, Position 35, B+ Position 20, Belt Adjustment Bracket Hole Position 10, Total Length 162.00, Remarks For pulley w/ 17.00 mm bore use bushing: HC-CARGO 134894.
