F032110374 - Alternator
Trade number 110374
Replacing and BOMs
OEM number
AIA105ATK
AIA104ATK
2706087701000DAIHATSU
2706087704000DAIHATSU
2706087705000DAIHATSU
2706097705000DAIHATSU
1735664015KUBOTA
2706087701TOYOTA
11925477200YANMAR
Competitor References
DRA3461AC DELCO
DRA6641AC DELCO
40130AD KÜHNER
40160RIAD KÜHNER
553415RIAD KÜHNER
A6188AUTOSTARTER POLAND
0986036641BOSCH
CAL40100CASCO SRL
CAL40412CASCO SRL
CAL40417CASCO SRL
115502040CV PSH
115530045CV PSH
695518045CV PSH
115002040CV PSH
DRA6641DELCO REMY
DRA3461DELCO REMY
1012112841DENSO
0210800870DENSO
1002116802DENSO
1002116803DENSO
DAN2018DENSO
217001402DRI
217102452DRI
280968ELSTOCK
283714ELSTOCK
210148ERA SPA
210148AERA SPA
12060014EUROTEC
12060021EUROTEC
118348FACROM
118775FACROM
9051600FRIESEN
9051608FRIESEN
1851608FRIESEN
110374HC-CARGO
JA160IRHC-PARTS
8EL726306001HELLA
J5116008HERTH U. BUSS
LRA00142LUCAS
LRA00543LUCAS
LRA01857LUCAS
943346068MARELLI
943346068010MARELLI
MAR6068MARELLI
9051600QUINTON HAZELL
9051608QUINTON HAZELL
QA1075QUINTON HAZELL
2516SPIDAN
55596SUDEST
55934SUDEST
436498VALEO
436525VALEO
VA298VALEO
437153VALEO
12180NWAI
12180RWAI
20543RWAI
ALT30004WOOD AUTO SUPPL
ALT30035WOOD AUTO SUPPL
F032110374 - Alternator
Details & description
Voltage 14, Amp 45, Pulley P, Bracket Hole Size 1 10.50, Pulley Diameter 63.00, Prod. info BN, D+ Size Plug, D+ Position 2, Holder Arm Width 19.00, Pulley Distance 43.50, Servicing Daihatsu, B+ M5, Radius 2 75.00, Plug no. 1 PL10, Radius 78.00, Rotation CW, Belt Adjustment Bracket Hole 1 M8, Grooves/pulley 1, Regulator type IR, Position 17, B+ Position 35, Belt Adjustment Bracket Hole Position 60, Total Length 169.00
Product information
Voltage:14
Amp:45
Pulley:P
Bracket Hole Size 1:10.50
Pulley Diameter:63.00
Prod. info:BN
D+ Size:Plug
D+ Position:2
Holder Arm Width:19.00
Pulley Distance:43.50
Servicing:Daihatsu
B+:M5
Radius 2:75.00
Plug no. 1:PL10
Radius:78.00
Rotation:CW
Belt Adjustment Bracket Hole 1:M8
Grooves/pulley:1
Regulator type:IR
Position:17
B+ Position:35
Belt Adjustment Bracket Hole Position:60
Total Length:169.00
Replacing and BOMs
OEM number
AIA105ATK
AIA104ATK
2706087701000DAIHATSU
2706087704000DAIHATSU
2706087705000DAIHATSU
2706097705000DAIHATSU
1735664015KUBOTA
2706087701TOYOTA
11925477200YANMAR
Competitor References
DRA3461AC DELCO
DRA6641AC DELCO
40130AD KÜHNER
40160RIAD KÜHNER
553415RIAD KÜHNER
A6188AUTOSTARTER POLAND
0986036641BOSCH
CAL40100CASCO SRL
CAL40412CASCO SRL
CAL40417CASCO SRL
115502040CV PSH
115530045CV PSH
695518045CV PSH
115002040CV PSH
DRA6641DELCO REMY
DRA3461DELCO REMY
1012112841DENSO
0210800870DENSO
1002116802DENSO
1002116803DENSO
DAN2018DENSO
217001402DRI
217102452DRI
280968ELSTOCK
283714ELSTOCK
210148ERA SPA
210148AERA SPA
12060014EUROTEC
12060021EUROTEC
118348FACROM
118775FACROM
9051600FRIESEN
9051608FRIESEN
1851608FRIESEN
110374HC-CARGO
JA160IRHC-PARTS
8EL726306001HELLA
J5116008HERTH U. BUSS
LRA00142LUCAS
LRA00543LUCAS
LRA01857LUCAS
943346068MARELLI
943346068010MARELLI
MAR6068MARELLI
9051600QUINTON HAZELL
9051608QUINTON HAZELL
QA1075QUINTON HAZELL
2516SPIDAN
55596SUDEST
55934SUDEST
436498VALEO
436525VALEO
VA298VALEO
437153VALEO
12180NWAI
12180RWAI
20543RWAI
ALT30004WOOD AUTO SUPPL
ALT30035WOOD AUTO SUPPL
