F032110417 - Starter
Trade number 110417Details & description
kW 1.3, Voltage 12, Drive type Steel, No./mount. holes 2 (0), Mounting Hole 2 11.00, Rear Distance 138.00, Thread Length 15.00, Gear type GR, Prod. info BN, Waterproof No, Front Distance 53.00, Drive Distance 17.50, No./teeth 9,11, B+ M8, Terminal 50 6.30, Mounting Flange 89.00, Distance 131.50, Oil sealed No, Rotation CW, Position 60, Mounting Hole 1 11.00, Amount of Mounting Holes 2 (0), Total Length 194.00
Product information
kW:1.3
Voltage:12
Drive type:Steel
No./mount. holes:2 (0)
Mounting Hole 2:11.00
Rear Distance:138.00
Thread Length:15.00
Gear type:GR
Prod. info:BN
Waterproof:No
Front Distance:53.00
Drive Distance:17.50
No./teeth:9,11
B+:M8
Terminal 50:6.30
Mounting Flange:89.00
Distance:131.50
Oil sealed:No
Rotation:CW
Position:60
Mounting Hole 1:11.00
Amount of Mounting Holes:2 (0)
Total Length:194.00
Replacing and BOMs
OEM number
SJ00203RAIM
AYS900ATK
AM880978JOHN DEERE
M809215JOHN DEERE
11986577010YANMAR
Competitor References
DRS3259AC DELCO
20729AD KÜHNER
20728AD KÜHNER
SHI0141AKS DASIS
SND0413AKS DASIS
SHI0141ARROWHEAD
SND0413ARROWHEAD
0986016081BOSCH
CST20136CASCO SRL
CST20181CASCO SRL
980501112CV PSH
DRS3259DELCO REMY
S8551DIXIE ELECTRIC
682004112DRI
251061ELSTOCK
220823ERA SPA
220823AERA SPA
106172FACROM
8080016FRIESEN
110417HC-CARGO
JS729HC-PARTS
8EA730269001HELLA
S114231BHITACHI
18207LESTER
LRS01124LUCAS
PBNS3025PRESTOLITE ELECTRIC
8080016QUINTON HAZELL
4252SPIDAN
33516SUDEST
18426NWAI
91251131WILSON
STR23004WOOD AUTO SUPPL
