Details & description

Insulated return Yes, Voltage 24, kW 6.5, Drive type Steel, Mounting Hole 2 16.80, Rear Distance 350.00, Prod. info BN, Waterproof No, Distance 3 126.00, Drive Distance 46.00, Distance 2 126.00, Mounting Flange 92.00, Distance 126.00, Info w/ rotating D.E. Bracket., Mounting Hole 3 16.80, Oil sealed Yes, No./mount. holes 3 (0), Gear type DD, B- 1/2" UNC, Front Distance 103.00, No./teeth 11, B+ 1/2" UNC, Terminal 50 3/16" UNF, Rotation CW, Position 15, Mounting Hole 1 16.80, B+ Position 60, Total Length 497.50, Remarks Replacing: 42MT., Amount of Mounting Holes 3 (0)
