Details & description

Voltage 14, Amp 80, Pulley SP, Pulley Diameter 54.40, Prod. info BN, Bracket Hole Size Rear M10, D+ Position 59, Pulley Distance 42.00, Servicing Peugeot, Citroen, Fiat, Mounting Bracket Distance 45.00, Radius 90.00, Belt Adjustment Bracket Hole 1 10.00, Grooves/pulley 6, Regulator type IR, Bracket Hole Size 1 10.20, Terminal type L-DFM, D+ Size Plug, Holder Arm Width 22.00, B+ M8, Radius 2 90.00, One Wire hookup (Self exciting) Yes, Plug no. 1 PL72, Rotation CW, Position 10, B+ Position 3, Belt Adjustment Bracket Hole Position 47, Total Length 162.00

Product information
