Voltage 14, Amp 150, Communication LIN, Pulley SP/FW, Pulley Diameter 53.50, Bracket Hole Size Rear M10, Pulley Distance 42.50, Remarks 3 This Alternator has a COM terminal on the regulator. It is recommended that the OEM number is used to check suitability before ordering., Source Valeo, Mounting Bracket Distance 45.00, Radius 90.00, Belt Adjustment Bracket Hole 1 10.00, Grooves/pulley 6, Regulator type IR, Bracket Hole Size 1 10.70, Terminal type COM, Holder Arm Width 21.00, B+ M8, Radius 2 90.00, Plug no. 1 PL174, Rotation CW, B+ Position 10, Belt Adjustment Bracket Hole Position 48, Total Length 190.00
Product information
Voltage:14
Amp:150
Communication:LIN
Pulley:SP/FW
Pulley Diameter:53.50
Bracket Hole Size Rear:M10
Pulley Distance:42.50
Remarks 3:This Alternator has a COM terminal on the regulator. It is recommended that the OEM number is used to check suitability before ordering.
