Details & description

Voltage 14, Amp 150, Communication BSS, Pulley SP/FW, Pulley Diameter 48.50, Prod. info BN, Bracket Hole Size Rear M8, Pulley Distance 33.00, Remarks 3 This Alternator has a COM terminal on the regulator. It is recommended that the OEM number is used to check suitability before ordering., Mounting Bracket Distance 60.80, Radius 90.00, Belt Adjustment Bracket Hole 1 8.50, Grooves/pulley 7, Regulator type IR, Bracket Hole Size 1 8.50, Terminal type COM, Holder Arm Width 14.00, B+ M8, Radius 2 90.00, Plug no. 1 PL131, Rotation CW, Position 60, B+ Position 50, Belt Adjustment Bracket Hole Position 45, Total Length 192.00
