Voltage 14, Amp 150, Communication BSS, Pulley SP/FW, Pulley Diameter 55.00, Bracket Hole Size Rear M8, Pulley Distance 38.70, Remarks 3 This Alternator has a COM terminal on the regulator. It is recommended that the OEM number is used to check suitability before ordering., Source Valeo, Mounting Bracket Distance 61.00, Radius 90.00, Belt Adjustment Bracket Hole 1 8.50, Grooves/pulley 6, Regulator type IR, Bracket Hole Size 1 8.50, Belt Adjustment Bracket Hole 2 M8, Terminal type COM, Holder Arm Width 14.00, B+ M8, Radius 2 90.00, Plug no. 1 PL131, Rotation CW, Position 2, B+ Position 52, Belt Adjustment Bracket Hole Position 45, Total Length 196.00
Product information
Voltage:14
Amp:150
Communication:BSS
Pulley:SP/FW
Pulley Diameter:55.00
Bracket Hole Size Rear:M8
Pulley Distance:38.70
Remarks 3:This Alternator has a COM terminal on the regulator. It is recommended that the OEM number is used to check suitability before ordering.
