Details & description

Voltage 14, Amp 85, Pulley SP, Bracket Hole Size 1 10.50, Pulley Diameter 63.00, Prod. info BN, Bracket Hole Size Rear 10.50, D+ Size Plug, D+ Position 58, Holder Arm Width 13.00, Pulley Distance 48.00, B+ M8, Radius 2 90.00, Plug no. 1 PL68, Mounting Bracket Distance 45.00, Radius 90.00, Rotation CW, Belt Adjustment Bracket Hole 1 8.50, Grooves/pulley 5, Regulator type IR, B+ Position 50, Belt Adjustment Bracket Hole Position 60, Total Length 166.00
