F032115453 - Alternator
Trade number 115453Details & description
Voltage 14, Amp 110, Pulley SP, Pulley Diameter 54.00, Prod. info BN, Bracket Hole Size Rear 8.50, D+ Position 53, Pulley Distance 46.00, Mounting Bracket Distance 80.00, Radius 90.00, Belt Adjustment Bracket Hole 1 M8, Grooves/pulley 5, Regulator type IR, Bracket Hole Size 1 8.50, Terminal type L-S-C, D+ Size Plug, Holder Arm Width 13.00, B+ M8, Fan IF, Radius 2 85.00, Plug no. 1 PL163, Rotation CW, Position 8, B+ Position 45, Belt Adjustment Bracket Hole Position 60, Total Length 168.00
Product information
Voltage:14
Amp:110
Pulley:SP
Pulley Diameter:54.00
Prod. info:BN
Bracket Hole Size Rear:8.50
D+ Position:53
Pulley Distance:46.00
Mounting Bracket Distance:80.00
Radius:90.00
Belt Adjustment Bracket Hole 1:M8
Grooves/pulley:5
Regulator type:IR
Bracket Hole Size 1:8.50
Terminal type:L-S-C
D+ Size:Plug
Holder Arm Width:13.00
B+:M8
Fan:IF
Radius 2:85.00
Plug no. 1:PL163
Rotation:CW
Position:8
B+ Position:45
Belt Adjustment Bracket Hole Position:60
Total Length:168.00
Replacing and BOMs
OEM number
A003TG4291MITSUBISHI
23700AA520SUBARU
23700AA521SUBARU
23700AA522SUBARU
23700AA570SUBARU
23700AA860SUBARU
Competitor References
DRA0366AC DELCO
DRA0388AC DELCO
553265RIAD KÜHNER
A5060AUTOSTARTER POLAND
A5192AUTOSTARTER POLAND
0986JR1212BOSCH
F042205155BOSCH
0986084440BOSCH
CAL35183CASCO SRL
175510110CV PSH
DRA0366DELCO REMY
DRA0388DELCO REMY
2331171002DRI
2331201102DRI
2331171102DRI
284928ELSTOCK
285523ELSTOCK
210955ERA SPA
210955AERA SPA
12060971EUROTEC
113012FACROM
9090839FRIESEN
115453HC-CARGO
CA2084IRHC-PARTS
8EL011713191HELLA
J5117022HERTH U. BUSS
LRA02810LUCAS
LRA02909LUCAS
11226NWAI
11225NWAI
