Details & description

Voltage 14, Amp 150, Communication BSS, Pulley SP, Pulley Diameter 54.00, Prod. info BN, Bracket Hole Size Rear M10, Pulley Distance 42.00, Remarks 3 This Alternator has a COM terminal on the regulator. It is recommended that the OEM number is used to check suitability before ordering., Mounting Bracket Distance 45.00, Radius 90.00, Belt Adjustment Bracket Hole 1 10.50, Grooves/pulley 6, Regulator type IR, Bracket Hole Size 1 10.50, Terminal type COM, Holder Arm Width 21.00, B+ M8, Radius 2 90.00, Plug no. 1 PL129, Rotation CW, Position 50, B+ Position 2, Belt Adjustment Bracket Hole Position 47, Total Length 178.00
