Details & description

Voltage 14, Amp 80, Communication LIN, Pulley SP/FW, Pulley Diameter 54.00, Bracket Hole Size Rear M10, Pulley Distance 42.40, Remarks 3 This Alternator has a COM terminal on the regulator. It is recommended that the OEM number is used to check suitability before ordering., Source Denso, Mounting Bracket Distance 45.80, Radius 90.00, Belt Adjustment Bracket Hole 1 10.50, Grooves/pulley 6, Regulator type IR, Bracket Hole Size 1 10.50, Belt Adjustment Bracket Hole 2 M10, Terminal type COM, Holder Arm Width 21.00, B+ M8, Radius 2 90.00, Plug no. 1 PL132, Rotation CW, Position 45, B+ Position 60, Belt Adjustment Bracket Hole Position 45, Total Length 177.50
