Details & description

Voltage 28, Amp 150, Pulley SP, W plug type Plug, Pulley Diameter 106.00, Prod. info BN, Bracket Hole Size Rear M12, D+ Position 3, Pulley Distance 48.00, Mounting Bracket Distance 95.50, Radius 120.00, Belt Adjustment Bracket Hole 1 12.50, Grooves/pulley 10, Regulator type IR, Bracket Hole Size 1 12.50, D+ Size Plug, Holder Arm Width 18.00, B+ M10, Radius 2 120.00, Plug no. 1 PL82, Rotation CW, Position 9, B+ Position 45, Belt Adjustment Bracket Hole Position 43, Total Length 235.00
