Details & description

Voltage 12, kW 1.4, Drive type Steel, Rear Distance 154.50, Prod. info BN, Waterproof No, Distance 3 83.00, Drive Distance 14.00, Distance 2 74.50, Distance 115.50, Mounting Hole 3 M8, Oil sealed No, No./mount. holes 3 (2), Gear type GR, Front Distance 45.50, No./teeth 10,12, B+ M8, Terminal 50 M6, Rotation CW, Position 20, Mounting Hole 1 9.00, B+ Position 60, Total Length 200.00, Amount of Mounting Holes 3 (2)
