Details & description

Voltage 14, Amp 130, Pulley SP/FW, Bracket Hole Size 1 10.50, Pulley Diameter 57.00, Bracket Hole Size Rear M10-1.25, Holder Arm Width 50.30, Pulley Distance 33.40, B+ M8, Radius 2 97.00, Plug no. 1 PL176, Mounting Bracket Distance 50.30, Radius 86.00, Rotation CW, Belt Adjustment Bracket Hole 1 11.00, Grooves/pulley 5, Regulator type IR, Position 45, B+ Position 38, Belt Adjustment Bracket Hole Position 50, Total Length 175.50
