Details & description

Voltage 14, Amp 120, Pulley SP, Bracket Hole Size 1 10.50, Pulley Diameter 55.00, Terminal type IG-L-S, D+ Size Plug, D+ Position 60, Holder Arm Width 58.00, Pulley Distance 90.00, B+ M8, Fan IF, Radius 2 85.50, Plug no. 1 PL11, Radius 83.00, Rotation CW, Belt Adjustment Bracket Hole 1 M8, Grooves/pulley 5, B+ Position 7, Belt Adjustment Bracket Hole Position 55, Total Length 187.00
