Details & description

Voltage 28, Amp 150, Communication LIN, Pulley SP, Bracket Hole Size 1 10.20, Pulley Diameter 69.00, Bracket Hole Size Rear 12.00, Terminal type COM, Holder Arm Width 80.00, Pulley Distance 38.00, B+ M8, Fan IF, Radius 2 95.00, Remarks 3 This Alternator has a COM terminal on the regulator. It is recommended that the OEM number is used to check suitability before ordering., Plug no. 1 PL190, Mounting Bracket Distance 108.00, Radius 95.00, Rotation CW, Belt Adjustment Bracket Hole 1 10.20/12.00, Grooves/pulley 8, B+ Position 58, Total Length 205.00
