Details & description

Voltage 14, Amp 180, Communication LIN, Pulley SP/FW, Pulley Diameter 55.00, Bracket Hole Size Rear 10.80, Pulley Distance 37.00, ID Code 17, Remarks 3 This Alternator has a COM terminal on the regulator. It is recommended that the OEM number is used to check suitability before ordering., Mounting Bracket Distance 83.00, Radius 96.50, Belt Adjustment Bracket Hole 1 11.00, Grooves/pulley 6, Regulator type IR, Bracket Hole Size 1 10.50, Terminal type COM, Holder Arm Width 14.00, B+ M8, Fan IF, Radius 2 95.00, Plug no. 1 PL174, Rotation CW, B+ Position 12, Belt Adjustment Bracket Hole Position 11, Total Length 187.00
