Details & description

Terminal IF, Voltage 14, Amp 110, Communication LIN, Pulley SP/FW, Pulley Diameter 59.00, Bracket Hole Size Rear 12.50, Pulley Distance 43.00, Remarks 3 This Alternator has a COM terminal on the regulator. It is recommended that the OEM number is used to check suitability before ordering., Mounting Bracket Distance 74.00, Radius 87.50, Belt Adjustment Bracket Hole 1 11.00, Grooves/pulley 7, Regulator type IR, Bracket Hole Size 1 10.40, Terminal type COM, Holder Arm Width 61.00, B+ M8, Fan IF, Radius 2 87.50, Plug no. 1 PL137, Rotation CW, B+ Position 20, Total Length 180.00
