Details & description

Voltage 14, Amp 130, Pulley SP, Pulley Diameter 55.00, Bracket Hole Size Rear 10.50, D+ Position 7, Pulley Distance 39.00, Mounting Bracket Distance 75.00, Radius 85.00, Belt Adjustment Bracket Hole 1 M8, Grooves/pulley 7, Regulator type IR, Bracket Hole Size 1 10.50, Lamp type Inactive, Terminal type L-S-C, D+ Size Plug, Holder Arm Width 13.00, B+ M8, Fan IF, Radius 2 88.00, Plug no. 1 PL163, Rotation CW, B+ Position 3, Belt Adjustment Bracket Hole Position 57, Total Length 155.00
