Details & description

Terminal IF, Voltage 14, Amp 140, Pulley DP, Pulley Diameter 70.00, Bracket Hole Size Rear 12.50, D+ Position 2, Pulley Distance 43.50, Mounting Bracket Distance 60.50, Radius 90.00, Belt Adjustment Bracket Hole 1 M8, Grooves/pulley 2, Regulator type IR, Bracket Hole Size 1 12.50, D+ Size Plug, Holder Arm Width 13.50, B+ M8, Fan IF, Radius 2 87.50, Plug no. 1 PL07, Rotation CW, B+ Position 8, Belt Adjustment Bracket Hole Position 3, Total Length 184.00

Product information
