F032116716 - Alternator

Trade number 116716
Product image - main
Trade number 116716

Details & description

Voltage 14, Amp 140, Communication LIN, Pulley SP/FW, Pulley Diameter 56.00, Bracket Hole Size Rear 8.00x9.40, Pulley Distance 29.50, ID Code 25, Remarks 3 This Alternator has a COM terminal on the regulator. It is recommended that the OEM number is used to check suitability before ordering., Mounting Bracket Distance 56.00, Radius 81.50, Belt Adjustment Bracket Hole 1 8.50, Grooves/pulley 6, Regulator type IR, Bracket Hole Size 1 9.00, Terminal type COM, Holder Arm Width 70.00, B+ M8, Fan IF, Radius 2 81.50, Plug no. 1 PL181, Rotation CW, B+ Position 45, Total Length 191.00

Product information

Electrical information

  • Voltage14
  • Amp140

Catalogue information

  • Remarks 3This Alternator has a COM terminal on the regulator. It is recommended that the OEM number is used to check suitability before ordering.

Physical information

  • CommunicationLIN
  • PulleySP/FW
  • Pulley Diameter56.00
  • Bracket Hole Size Rear8.00x9.40
  • Pulley Distance29.50
  • ID Code25
  • Mounting Bracket Distance56.00
  • Radius81.50
  • Belt Adjustment Bracket Hole 18.50
  • Suggested Products

    Replacing and BOMs

    OEM number

    • 06J903023RVW (VOLKSWAGEN)

    Competitor References

    • 553578RIVAD KÜHNER
    • CAL15486CASCO SRL
    • 305911140CV PSH
    • 12090586EUROTEC
    • 116716HC-CARGO
    • TG14C056VALEOBOM
    • 439831VALEO
    • 440556VALEO
