F032116783 - Starter
Trade number 116783
Replacing and BOMs
OEM number
- 3499077CATERPILLAR
- 3499075CATERPILLAR
- 3964770CATERPILLAR
- 3545671CATERPILLAR
- 20R4879CATERPILLAR
Competitor References
- 255702AD KÜHNER
- S1223SAUTOSTARTER POLAND
- CST60626CASCO SRL
- 641547103CV PSH
- 4280009120DENSO
- DSN2146DENSO
- 4380000550DENSO
- 4280009121DENSO
- 4280009122DENSO
Trade number 116783
Details & description
kW 9.0, Voltage 24, No./mount. holes 3 (0), Mounting Hole 2 13.50, Rear Distance 340.00, Front Distance 54.00, Distance 3 126.50, Drive Distance 47.50, Distance 2 126.50, B+ M12, Terminal 50 M5, Mounting Flange 92.00, Distance 126.50, Mounting Hole 3 13.50, Rotation CW, Mounting Holes with Thread 0, Gear type GR, Mounting Hole 1 13.50, B+ Position 60, No./teeth 12, Amount of Mounting Holes 3, Total Length 394.00
Product information
Electrical information
- kW9.0
- Voltage24
Physical information
- No./mount. holes3 (0)
- Mounting Hole 213.50
- Rear Distance340.00
- Front Distance54.00
- Distance 3126.50
- Drive Distance47.50
- Distance 2126.50
- B+M12
- Terminal 50M5
