Terminal IF, Voltage 14, Amp 150, Remarks 3 This Alternator has a COM terminal on the regulator. It is recommended that the OEM number is used to check suitability before ordering., Bracket Hole Size 2 M8, Grooves/pulley 6, Regulator type IR, Belt Adjustment Bracket Hole 1 8.00, Mounting Bracket Distance 61.00, Radius 90.00, Pulley Diameter 49.00, Bracket Hole Size Rear M8, Communication LIN, Pulley SP/FW, Pulley Distance 38.50, Plug no. 1 PL131, Fan IF, Radius 2 90.00, B+ M8, Rotation CW, Bracket Hole Size 1 8.00, B+ Length 16.50, Terminal type COM, Holder Arm Width 14.50, Belt Adjustment Bracket Hole Position 15, Total Length 198.00, B+ Position 50
