Details & description

Voltage 14, Amp 33, Ring Height 1 11.00, Current coil 2.65, Core type Loose, Ring Height 2 9.20, Slip Ring End Length 45.00, Bearing Diameter 12.00, Cooling fan w/o, Thread size M16-1.50, Outer Diameter 73.40, Wire Diameter 0.65, Thread Length 13.50, Slip Ring Rear 86.00, Slip Ring Outer Diameter 27.60, Wire weight 168, Core Diameter 38.60, Ring Distance 2.20, Bobine measurement 64.60, Drive End Length 55.50, Windings 440, Core height 25.00, Slip Ring Front 74.60, Rotation CW, Height 46.60, Total Length 22.20;147.00, Shaft Diameter 17.00

Product information
