F032132940 - Solenoid Switch

Trade number 132940
Product image - main
Trade number 132940

Details & description

Intermittent load 100 Amp., Voltage 24, Amp 60, Seconds 5, No./mount. holes 2, No./terminals 4, Outer Diameter 42.00, Amount of Mounting Holes 2, Remarks Insulated. N.O. Terminals: 5/16" UNF. Coil Terminals: 10-32 UNF., Total Length 66.50

Product information

Intermittent load:100 Amp.
Voltage:24
Amp:60
Seconds:5
No./mount. holes:2
No./terminals:4
Outer Diameter:42.00
Amount of Mounting Holes:2
Remarks:Insulated. N.O. Terminals: 5/16" UNF. Coil Terminals: 10-32 UNF.
Total Length:66.50

Replacing and BOMs

OEM number

132940UNIVERSAL

Competitor References

71020ACCURATE
ARE6005AUTOSTARTER POLAND
F042S10222BOSCH
F042010222BOSCH
033547DURITE
TL2GUARDIAN
132940HC-CARGO
SNLS24AUNIPOINT
677031WAI
67703WAI
SND12004WOOD AUTO SUPPL
