Details & description

Voltage 14, Amp 95;120, Ring Height 1 10.00, Current coil 3.85, Core type Loose, Ring Height 2 9.90, Slip Ring End Length 49.50, Wing height 78.30, Cooling fan w/, Thread size M16-1.50, Outer Diameter 98.00, Wire Diameter 0.80, Thread Length 12.50, Slip Ring Rear 113.00, Slip Ring Outer Diameter 14.50, Core Diameter 54.30, Ring Distance 2.00, Bobine measurement 76.60, Drive End Length 46.80, Windings 396, Core height 30.30, Slip Ring Front 100.40, Rotation CW, Height 55.30, Total Length 152.00, Shaft Diameter 17.00
