Details & description

kW 2.0, Voltage 12, Commutator Diameter 33.00, Commutator Distance 19.70, OD/spline/teeth 15.00, No./bars 23, Commutator Height 35.20, Bar length 5.50, Commutator Inner Diameter 12.90, Bar Distance 3.45, No./teeth 9, Core Diameter 59.00, Shaft length 149.00, Bar Cross Distance 41.20, Commutator End Shaft Diameter 10.00, Bar Lane Height 22.00, Spline Teeth Length 24.50, Drive End Inside Shaft Diameter Outside 8.00, Commutator Outer Diameter 52.40, Rotation CW, Shaft Diameter 19.00
