Details & description

kW 1.1/1.8, Voltage 12, Commutator Diameter 33.00, Commutator Distance 19.60, OD/spline/teeth 17.00, No./bars 28, Commutator Height 32.40, Bar length 5.50, Commutator Inner Diameter 13.00, Bar Distance 2.75, Core Diameter 55.00, Shaft length 136.00, Bar Cross Distance 41.80, Commutator End Shaft Diameter 10.00, Bar Lane Height 19.20, Spline Teeth Length 19.00, Drive End Inside Shaft Diameter Outside 8.00, Commutator Outer Diameter 53.00, Rotation CW/CCW, No./teeth 11
