Alternators
F032110112 - AlternatorTrade number 110112
Terminal W,Voltage 28,Amp 40,Pulley w/o,W plug type M5,Bracket Hole Size 1 11.50,Prod. info BN,D+ Size M4,D+ Position 55,Holder Arm Width 51.00,Servicing Volvo,B+ M6,Fan EF,Radius 2 90.00,Radius 90.00,Belt Adjustment Bracket Hole 1 8.20,Regulator type IR,Position 25,B+ Position 10,Belt Adjustment Bracket Hole Position 57,Total Length 175.50
F032110113 - AlternatorTrade number 110113
Voltage 28,Amp 27,Pulley w/o,W plug type M5,Bracket Hole Size 1 10.00,Belt Adjustment Bracket Hole 2 12.00,Prod. info BN,D+ Size M4,D+ Position 2,Holder Arm Width 80.00,Servicing Mercedes-Benz,Radius 3 86.00,B+ M6,Radius 2 86.00,Radius 86.00,Rotation CCW,Belt Adjustment Bracket Hole 1 12.00,Regulator type IR,Position 33,B+ Position 18,Belt Adjustment Bracket Hole Position 10;50,Total Length 165.00
F032110116 - AlternatorTrade number 110116
Terminal W,Voltage 28,Amp 35,Pulley w/o,W plug type M5,Bracket Hole Size 1 10.00,Belt Adjustment Bracket Hole 2 10.00,Prod. info BN,D+ Size M4,D+ Position 30,Holder Arm Width 80.00,Servicing DAF, MAN,Radius 3 86.00,B+ M8,Radius 2 86.00,Radius 90.00,Rotation CW,Belt Adjustment Bracket Hole 1 10.00,Regulator type IR,Position 60,B+ Position 45,Belt Adjustment Bracket Hole Position 56;4,Total Length 180.00
F032110163 - AlternatorTrade number 110163
Voltage 28,Amp 45,Terminal W,Pulley DP,W plug type M5,Pulley Diameter 73.00,Prod. info BN,Bracket Hole Size Rear 10.00,D+ Position 15,Pulley Distance 48.70,Servicing Renault,Mounting Bracket Distance 67.50,Radius 81.00,Belt Adjustment Bracket Hole 1 M8,Grooves/pulley 2,Regulator type IR,Bracket Hole Size 1 11.00,D+ Size M5,Holder Arm Width 27.20,B+ M6,Fan EF,Radius 2 86.50,Rotation CW,Position 60,B+ Position 45,Belt Adjustment Bracket Hole Position 3,Total Length 172.50
F032110179 - AlternatorTrade number 110179
Voltage 14,Amp 36,Pulley w/o,Prod. info BN/OE,Bracket Hole Size Rear 8.20,D+ Position 20,Servicing Ford, Land Rover, Triumph, Vauxhall, Lotus, Jaguar, Mercury,Source Lucas,Mounting Bracket Distance 88.00,Radius 81.00,Belt Adjustment Bracket Hole 1 8.20,Regulator type IR,Bracket Hole Size 1 8.20,D+ Size 6.30,Holder Arm Width 9.70,B+ 9.40,Radius 2 83.00,Plug no. 1 PL22,Rotation CW,Position 35,B+ Position 20,Belt Adjustment Bracket Hole Position 10,Total Length 162.00,Remarks For pulley w/ 17.00 mm bore use bushing: HC-CARGO 134894.
F032110300 - AlternatorTrade number 110300
Terminal W,Voltage 28,Amp 65,Pulley w/o,Bracket Hole Size 1 12.00,Prod. info BN,Bracket Hole Size Rear 13.00,Holder Arm Width 12.00,Servicing International, Case,B+ M6,Radius 2 117.50,One Wire hookup (Self exciting) Yes,Mounting Bracket Distance 103.00,Radius 116.00,Rotation CW,Belt Adjustment Bracket Hole 1 1/2" UNC,Regulator type IR,Remarks Replacing: 27SI. Shaft diameter: 22.00 mm. Fan: HC-CARGO 131854.,B+ Position 57,Belt Adjustment Bracket Hole Position 60,Total Length 226.50
F032110679 - AlternatorTrade number 110679
Voltage 14,Amp 60,Pulley SP,Bracket Hole Size 1 10.20,Pulley Diameter 56.00,Prod. info Reman,D+ Size Plug,D+ Position 60,Holder Arm Width 58.00,Pulley Distance 92.20,Servicing Isuzu, Opel,B+ M6,Radius 2 93.00,Plug no. 1 PL11,Radius 89.00,Rotation CW,Belt Adjustment Bracket Hole 1 M8,Grooves/pulley 4,Regulator type IR,Position 50,B+ Position 7,Belt Adjustment Bracket Hole Position 60,Total Length 166.50
F032110701 - AlternatorTrade number 110701
Voltage 14,Amp 50,Pulley DP,Pulley Diameter 86.00,Prod. info BN,Bracket Hole Size Rear 10.40,Nipple Vaccum Pump Position 23,Pulley Distance 41.80,Servicing Nissan,Vac. pump Yes,Mounting Bracket Distance 80.50,Radius 88.50,Belt Adjustment Bracket Hole 1 M8,Grooves/pulley 2,Regulator type IR,Bracket Hole Size 1 10.40,Vacumm Pump Position 55,Holder Arm Width 13.30,B+ M6,Radius 2 84.00,Plug no. 1 PL07,Rotation CW,B+ Position 43,Belt Adjustment Bracket Hole Position 60,Total Length 258.00
F032110766 - AlternatorTrade number 110766
Terminal W,Voltage 28,Amp 27,Pulley w/o,W plug type M5,Bracket Hole Size 1 8.20,Belt Adjustment Bracket Hole 2 8.20,Prod. info BN,D+ Size M4,D+ Position 43,Holder Arm Width 56.00,Servicing Atlas Copco, Iveco, Mercedes,Radius 3 79.50,B+ M6,Radius 2 79.50,Radius 85.00,Rotation CW,Belt Adjustment Bracket Hole 1 8.20,Regulator type IR,Position 15,B+ Position 60,Belt Adjustment Bracket Hole Position 10;50,Total Length 170.00
F032110801 - AlternatorTrade number 110801
Terminal W,Voltage 28,Amp 45,Pulley w/o,W plug type 10-24 UNC,Bracket Hole Size 1 13.00,Prod. info BN,Holder Arm Width 14.80,Servicing Fiat-Allis, International, Cummins, Caterpillar, Atlas Corpo, Case,B+ 1/4" UNF,Radius 2 100.00,Mounting Bracket Distance 100.00,Radius 100.00,Rotation CW/CCW,Belt Adjustment Bracket Hole 1 1/2" UNC,B+ Position 55,Belt Adjustment Bracket Hole Position 60,Total Length 270.00
