Solenoids
F032130493 - Solenoid SwitchTrade number 130493
Intermittent load 150 Amp,Voltage 12,No./mount. holes 2,No./terminals 4,Outer Diameter 42.30,Amount of Mounting Holes 2,Remarks N.O. Terminals: 5/16" UNF. Coil Terminals: 10-32 UNF.,Total Length 62.50
F032131370 - Solenoid SwitchTrade number 131370
Intermittent load 500 Amp,Voltage 12,Amp 80,Seconds 5,No./terminals 4,Outer Diameter 52.00,Remarks Water proof. Silver contact. Insulated return. N.O. Terminals: M8. Coil Terminals: 6.30 mm.,Total Length 102.00
F032131371 - Solenoid SwitchTrade number 131371
Intermittent load 500 Amp.,Voltage 24,Amp 80,Seconds 5,No./mount. holes 2,No./terminals 4,Outer Diameter 51.70,Amount of Mounting Holes 2,Remarks Silver contact. Insulated return. N.O. terminals: M8. Coil Terminals: 6.30 mm.,Total Length 99.50
F032132939 - Solenoid SwitchTrade number 132939
Intermittent load 150 Amp.,Voltage 12,Amp 80,Seconds 5,No./mount. holes 2,No./terminals 4,Outer Diameter 41.80,Amount of Mounting Holes 2,Remarks Insulated. Delivered with nuts. N.O. Terminals: 5/16" UNF. Coil Terminals: 10-32 UNF.,Total Length 67.50
F032132940 - Solenoid SwitchTrade number 132940
Intermittent load 100 Amp.,Voltage 24,Amp 60,Seconds 5,No./mount. holes 2,No./terminals 4,Outer Diameter 42.00,Amount of Mounting Holes 2,Remarks Insulated. N.O. Terminals: 5/16" UNF. Coil Terminals: 10-32 UNF.,Total Length 66.50
F032133617 - Solenoid SwitchTrade number 133617
Intermittent load 50 Amp.,Voltage 24,Amp 50,Seconds 5,No./mount. holes 2,Outer Diameter 41.70,Amount of Mounting Holes 2,Remarks Insulated return. Terminals: 5/16" UNF. Coil Terminals: 10-32 UNF.,Total Length 89.00
F032133695 - Solenoid SwitchTrade number 133695
Intermittent load 500 Amp.,Voltage 12,Amp 100,Seconds 5,No./mount. holes 2,No./terminals 4,Outer Diameter 47.70,Amount of Mounting Holes 2,Remarks Universal. N.O. Terminals: M8. Coil Terminals: M5.,Total Length 105.50
F032133855 - Solenoid SwitchTrade number 133855
Intermittent load 800 Amp,Voltage 12,Amp 100,No./mount. holes 2,No./terminals 3,Outer Diameter 48.50,Amount of Mounting Holes 2,Remarks 3.95-4.15 coil resistance. N.O. Terminals: 5/16" UNC. Coil Terminal: 10-32 UNF.,Total Length 55.50
F032133857 - Solenoid SwitchTrade number 133857
Intermittent load 800 Amp,Voltage 12,Amp 100,No./mount. holes 2,No./terminals 4,Outer Diameter 48.20,Amount of Mounting Holes 2,Remarks 3.95-4.15 coil resistance. N.O. Terminals: 5/16" UNC. Coil Terminals: 10-32 UNF.,Total Length 55.50
F032139857 - Solenoid SwitchTrade number 139857
Voltage 12,No./mount. holes 2,No./terminals 4,Outer Diameter 56.00,Amount of Mounting Holes 2,Remarks N.O. Terminals: M8. Coil Terminals: M4.,Total Length 55.50
