Starters
F032110160 - StarterTrade number 110160
kW 1.2,Voltage 12,Drive type Steel,No./mount. holes 2 (2),Rear Distance 158.00,Gear type DD/GR,Prod. info BN,Waterproof No,Front Distance 71.00,Drive Distance 35.00,No./teeth 9,B+ M8,Terminal 15a 6.30,Terminal 50 6.30,Mounting Flange 82.50,Distance 103.00,Oil sealed No,Rotation CW,Position 45;15,Amount of Mounting Holes 2 (2),Total Length 240.50
F032110210 - StarterTrade number 110210
Voltage 24,kW 6.6,Drive type Steel,Mounting Hole 2 13.50,Rear Distance 343.00,Prod. info BN,Waterproof No,Distance 3 126.50,Drive Distance 47.50,Distance 2 126.50,Mounting Flange 92.00,Distance 126.50,Mounting Hole 3 13.50,Oil sealed No,No./mount. holes 3 (0),Gear type DD,B- M10,Front Distance 61.00,No./teeth 9,B+ M12,Terminal 50 M6,Rotation CW,Position 60,Mounting Hole 1 13.50,Total Length 407.00,Remarks Not suitable for biogas plants.,Amount of Mounting Holes 3 (0)
F032110212 - StarterTrade number 110212
Voltage 24,kW 6.6,Drive type Steel,Mounting Hole 2 13.50,Rear Distance 338.00,Prod. info BN,Waterproof No,Distance 3 126.00,Drive Distance 48.00,Distance 2 126.00,Mounting Flange 92.00,Distance 126.00,Mounting Hole 3 13.50,Oil sealed No,No./mount. holes 3 (0),Gear type DD,B- M10,Front Distance 64.00,No./teeth 11,B+ M10,Terminal 50 M6,Rotation CW,Position 60,Mounting Hole 1 13.50,Total Length 407.00,Amount of Mounting Holes 3 (0)
F032110214 - StarterTrade number 110214
Insulated return Yes,Voltage 24,kW 6.6,Drive type Steel,Mounting Hole 2 16.70,Rear Distance 355.00,Prod. info BN,Waterproof No,Distance 3 125.00,Drive Distance 37.00,Distance 2 125.00,Mounting Flange 92.00,Distance 125.00,Mounting Hole 3 16.70,Oil sealed No,No./mount. holes 3 (0),Gear type DD,B- M10,Front Distance 52.00,No./teeth 11,B+ M10,Terminal 50 M6,Rotation CW,Position 60,Mounting Hole 1 16.70,Total Length 407.00,Amount of Mounting Holes 3 (0)
F032110216 - StarterTrade number 110216
kW 1.4,Voltage 12,Drive type Steel,No./mount. holes 2 (0),Mounting Hole 2 9.80,Rear Distance 180.00,Gear type GR,Prod. info BN,Waterproof No,Front Distance 54.00,Drive Distance 18.50,No./teeth 9,11,B+ M8,Terminal 15a M5,Terminal 50 M5,Distance 83.00,Oil sealed No,Rotation CW,Remarks Replacing: 10MT.,Position 40;10,Mounting Hole 1 9.80,Amount of Mounting Holes 2 (0),Total Length 234.00
F032110240 - StarterTrade number 110240
kW 0.6,Voltage 12,Drive type Steel,No./mount. holes 3 (0),Rear Distance 131.50,Gear type DD,Prod. info BN,Waterproof No,Front Distance 78.00,Drive Distance 44.00,No./teeth 9,B+ 1/4" UNC,Mounting Flange 63.50,Distance 71.50,Mounting Hole 3 9.50,Oil sealed No,Rotation CCW,Mounting Hole 1 8.50,Amount of Mounting Holes 3 (0),Total Length 209.00
F032110363 - StarterTrade number 110363
kW 0.7,Voltage 12,Drive type Steel,No./mount. holes 2 (0),Mounting Hole 2 12.00,Rear Distance 130.50,Gear type DD/GR,Prod. info BN,Waterproof No,Front Distance 69.00,Drive Distance 33.00,No./teeth 9,B+ M8,Terminal 50 6.30,Mounting Flange 76.00,Distance 105.00,Oil sealed No,Rotation CCW,Remarks Bushing D.E. (clutch house): HC-CARGO 140008.,Position 15,Mounting Hole 1 11.00,Amount of Mounting Holes 2 (0),Total Length 214.00
F032110436 - StarterTrade number 110436
Insulated return Yes,Voltage 12,Drive type Steel,Rear Distance 350.00,Prod. info BN,Waterproof No,Distance 3 126.50,Drive Distance 46.00,Distance 2 126.50,Mounting Flange 92.00,Distance 126.50,Mounting Hole 3 17.00,Oil sealed Yes,No./mount. holes 3 (0),Thread Length 28.00,Gear type DD,B- 1/2" UNC,Front Distance 101.50,No./teeth 12,B+ 1/2" UNC,Terminal 50 3/16" UNF,Rotation CW,Position 15;50,Total Length 496.00,Remarks Replacing: 42MT.,Amount of Mounting Holes 3 (0)
F032110438 - StarterTrade number 110438
Voltage 12,kW 2.1,Drive type Steel,Mounting Hole 2 11.00,Rear Distance 225.50,Prod. info BN,Waterproof No,Distance 3 90.50,Drive Distance 19.50,Distance 2 90.50,Mounting Flange 89.00,Distance 126.50,Mounting Hole 3 10.50,Oil sealed No,No./mount. holes 3 (0),Gear type DD,Front Distance 66.00,No./teeth 10,B+ M8,Terminal 50 9.50,Rotation CW,Position 10,Mounting Hole 1 11.00,Total Length 309.00,Amount of Mounting Holes 3 (0)
F032110443 - StarterTrade number 110443
Voltage 12,kW 2.1,Drive type Steel,Mounting Hole 2 11.00,Rear Distance 216.00,Prod. info BN,Waterproof No,Distance 3 89.50,Drive Distance 29.50,Distance 2 126.50,Mounting Flange 89.00,Distance 89.50,Mounting Hole 3 10.50,Oil sealed No,No./mount. holes 3 (0),Gear type DD,Front Distance 79.00,No./teeth 10,B+ M8,Terminal 50 6.30,Rotation CW,Position 10,Mounting Hole 1 11.00,Total Length 309.00,Amount of Mounting Holes 3 (0)
