Starters
F032110160 - StarterTrade number 110160
kW 1.2, Voltage 12, Drive type Steel, No./mount. holes 2 (2), Rear Distance 158.00, Prod. info BN, Waterproof No, Front Distance 71.00, Drive Distance 35.00, B+ M8, Terminal 15a 6.30, Terminal 50 6.30, Mounting Flange 82.50, Distance 103.00, Oil sealed No, Rotation CW, Mounting Holes with Thread 2, Position 45;15, Gear type DD;GR, No./teeth 9, Amount of Mounting Holes 2, Total Length 240.50
F032110210 - StarterTrade number 110210
kW 6.6, Voltage 24, Drive type Steel, Mounting Hole 2 13.50, Rear Distance 343.00, Prod. info BN, Waterproof No, Distance 3 126.50, Drive Distance 47.50, Distance 2 126.50, Mounting Flange 92.00, Distance 126.50, Mounting Hole 3 13.50, Oil sealed No, No./mount. holes 3 (0), B- M10, Front Distance 61.00, B+ M12, Terminal 50 M6, Rotation CW, Mounting Holes with Thread 0, Position 60, Mounting Hole 1 13.50, Total Length 407.00, Remarks Not suitable for biogas plants., Gear type DD, No./teeth 11, Amount of Mounting Holes 3
F032110212 - StarterTrade number 110212
kW 6.6, Voltage 24, Drive type Steel, Mounting Hole 2 13.50, Rear Distance 338.00, Prod. info BN, Waterproof No, Distance 3 126.00, Drive Distance 48.00, Distance 2 126.00, Mounting Flange 92.00, Distance 126.00, Mounting Hole 3 13.50, Oil sealed No, No./mount. holes 3 (0), B- M10, Front Distance 64.00, B+ M10, Terminal 50 M6, Rotation CW, Mounting Holes with Thread 0, Position 60, Mounting Hole 1 13.50, Total Length 407.00, Gear type DD, No./teeth 11, Amount of Mounting Holes 3
F032110214 - StarterTrade number 110214
Insulated return Yes, kW 6.6, Voltage 24, Drive type Steel, Mounting Hole 2 16.70, Rear Distance 355.00, Prod. info BN, Waterproof No, Distance 3 125.00, Drive Distance 37.00, Distance 2 125.00, Mounting Flange 92.00, Distance 125.00, Mounting Hole 3 16.70, Oil sealed No, No./mount. holes 3 (0), B- M10, Front Distance 52.00, B+ M10, Terminal 50 M6, Rotation CW, Mounting Holes with Thread 0, Position 60, Mounting Hole 1 16.70, Total Length 407.00, Gear type DD, No./teeth 11, Amount of Mounting Holes 3
F032110216 - StarterTrade number 110216
kW 1.4, Voltage 12, Drive type Steel, Mounting Hole 2 9.80, Rear Distance 180.00, Prod. info BN, Waterproof No, Drive Distance 18.50, Distance 83.00, Oil sealed No, No./mount. holes 2 (0), Front Distance 54.00, B+ M8, Terminal 15a M5, Terminal 50 M5, Rotation CW, Mounting Holes with Thread 0, Position 40;10, Mounting Hole 1 9.80, Total Length 234.00, Remarks Replacing: 10MT., Gear type GR, No./teeth 9;11, Amount of Mounting Holes 2
F032110240 - StarterTrade number 110240
kW 0.6, Voltage 12, Drive type Steel, No./mount. holes 3 (0), Rear Distance 131.50, Prod. info BN, Waterproof No, Front Distance 78.00, Drive Distance 44.00, B+ 1/4" UNC, Mounting Flange 63.50, Distance 71.50, Mounting Hole 3 9.50, Oil sealed No, Rotation CCW, Mounting Holes with Thread 0, Gear type DD, Mounting Hole 1 8.50, No./teeth 9, Amount of Mounting Holes 3, Total Length 209.00
F032110363 - StarterTrade number 110363
kW 0.7, Voltage 12, Drive type Steel, Mounting Hole 2 12.00, Rear Distance 130.50, Prod. info BN, Waterproof No, Drive Distance 33.00, Mounting Flange 76.00, Distance 105.00, Oil sealed No, No./mount. holes 2 (0), Front Distance 69.00, B+ M8, Terminal 50 6.30, Rotation CCW, Mounting Holes with Thread 0, Position 15, Mounting Hole 1 11.00, Total Length 214.00, Remarks Bushing D.E. (clutch house): HC-CARGO 140008., Gear type DD;GR, No./teeth 9, Amount of Mounting Holes 2
F032110436 - StarterTrade number 110436
Insulated return Yes, kW 3.3, Voltage 12, Drive type Steel, Rear Distance 350.00, Prod. info BN, Waterproof No, Distance 3 126.50, Drive Distance 46.00, Distance 2 126.50, Mounting Flange 92.00, Distance 126.50, Mounting Hole 3 17.00, Oil sealed Yes, No./mount. holes 3 (0), Thread Length 28.00, B- 1/2" UNC, Front Distance 101.50, B+ 1/2" UNC, Terminal 50 3/16" UNF, Rotation CW, Mounting Holes with Thread 0, Position 15;50, Total Length 496.00, Remarks Replacing: 42MT., Gear type DD, No./teeth 12, Amount of Mounting Holes 3
F032110438 - StarterTrade number 110438
kW 2.1, Voltage 12, Drive type Steel, Mounting Hole 2 11.00, Rear Distance 225.50, Prod. info BN, Waterproof No, Distance 3 90.50, Drive Distance 19.50, Distance 2 90.50, Mounting Flange 89.00, Distance 126.50, Mounting Hole 3 10.50, Oil sealed No, No./mount. holes 3 (0), Front Distance 66.00, B+ M8, Terminal 50 9.50, Rotation CW, Mounting Holes with Thread 0, Position 10, Mounting Hole 1 11.00, Total Length 309.00, Gear type DD, No./teeth 10, Amount of Mounting Holes 3
F032110443 - StarterTrade number 110443
kW 2.1, Voltage 12, Drive type Steel, Mounting Hole 2 11.00, Rear Distance 216.00, Prod. info BN, Waterproof No, Distance 3 89.50, Drive Distance 29.50, Distance 2 126.50, Mounting Flange 89.00, Distance 89.50, Mounting Hole 3 10.50, Oil sealed No, No./mount. holes 3 (0), Front Distance 79.00, B+ M8, Terminal 50 6.30, Rotation CW, Mounting Holes with Thread 0, Position 10, Mounting Hole 1 11.00, Total Length 309.00, Gear type DD, No./teeth 10, Amount of Mounting Holes 3
