Alternators
F032110052 - AlternatorTrade number 110052
Insulated return Yes, Terminal W, Voltage 28, Amp 40, Regulator type IR, Belt Adjustment Bracket Hole 1 8.20, Radius 84.00, Prod. info BN, Bracket Hole Size Rear 14.00, Pulley w/o, W plug type 6.30, D+ Position 5, Fan EF, Radius 2 82.00, B+ M6, Rotation CW, Bracket Hole Size 1 11.00, Holder Arm Width 50.00, D+ Size M5, Belt Adjustment Bracket Hole Position 55, Total Length 177.00, Position 38, B+ Position 50
F032110112 - AlternatorTrade number 110112
Terminal W, Voltage 28, Amp 40, Fan EF, Radius 2 90.00, B+ M6, Regulator type IR, Belt Adjustment Bracket Hole 1 8.20, Radius 90.00, Prod. info BN, Pulley w/o, W plug type M5, Bracket Hole Size 1 11.50, Servicing Volvo, Holder Arm Width 51.00, D+ Size M4, D+ Position 55, Belt Adjustment Bracket Hole Position 57, Total Length 175.50, Position 25, B+ Position 10
F032110127 - AlternatorTrade number 110127
Insulated return Yes, Terminal W, Voltage 14, Amp 70, Grooves/pulley 1, Regulator type IR, Belt Adjustment Bracket Hole 1 8.00, Radius 85.00, Pulley Diameter 64.00, Prod. info BN, Pulley P, W plug type 6.30, Pulley Distance 79.00, Servicing Volvo Penta, D+ Position 50, Fan EF, Radius 2 86.50, B+ M6, Rotation CW, Bracket Hole Size 1 11.00, Holder Arm Width 51.00, D+ Size M5, Belt Adjustment Bracket Hole Position 57, Total Length 179.00, Position 14, B+ Position 58
F032110173 - AlternatorTrade number 110173
Voltage 28, Amp 75, Radius 2 107.00, B+ M8, Rotation CW, Regulator type IR, Belt Adjustment Bracket Hole 1 1/2" UNC, Info NOTE! NOT with insulated return, Mounting Bracket Distance 101.50, Radius 105.00, Prod. info BN, Bracket Hole Size Rear 12.50, Pulley w/o, Bracket Hole Size 1 12.50, Servicing DAF, Clark, Holder Arm Width 14.50, D+ Size M6, D+ Position 45, Belt Adjustment Bracket Hole Position 60, Total Length 246.00, Position 60, B+ Position 15
F032110175 - AlternatorTrade number 110175
Insulated return Yes, Voltage 28, Amp 100, Belt Adjustment Bracket Hole 3 1/2" UNC, Radius 3 106.50, Regulator type IR, Belt Adjustment Bracket Hole 1 1/2" UNC, Mounting Bracket Distance 103.00, Radius 108.00, Prod. info BN, Bracket Hole Size Rear 13.00, Pulley w/o, Radius 4 107.50, Servicing Volvo, D+ Position 5, Fan EF, Radius 2 107.00, B+ M8, Rotation CW, Belt Adjustment Bracket Hole 2 1/2" UNC, Bracket Hole Size 1 13.00, Holder Arm Width 14.70, D+ Size M5, Belt Adjustment Bracket Hole Position 56;60;4, Total Length 249.00, Position 60, B+ Position 30, Remarks Fan: HC-CARGO 134317. Pulley: HC-CARGO 131176.
F032110176 - AlternatorTrade number 110176
Insulated return Yes, Terminal W, Voltage 28, Amp 175, Belt Adjustment Bracket Hole 3 1/2" UNC, Radius 3 100.00, Regulator type IR, Belt Adjustment Bracket Hole 1 1/2" UNC, Mounting Bracket Distance 101.50, Radius 108.00, Prod. info BN, Bracket Hole Size Rear 13.00, Pulley w/o, W plug type M5, Radius 4 104.00, Servicing Volvo Penta, D+ Position 15, Fan EF, Radius 2 107.00, B+ 5/16" UNC, Rotation CW, Belt Adjustment Bracket Hole 2 1/2" UNC, Bracket Hole Size 1 13.00, Holder Arm Width 14.70, D+ Size 10-24 UNC, Belt Adjustment Bracket Hole Position 55;60;5, Total Length 278.00, Position 60, B+ Position 30
F032110540 - AlternatorTrade number 110540
Terminal W, Voltage 14, Amp 55, Grooves/pulley 1, Regulator type IR, Belt Adjustment Bracket Hole 1 5/16" UNC, Radius 81.50, Pulley Diameter 73.50, Prod. info BN, Pulley P, W plug type Plug, Pulley Distance 75.00, Servicing Bobcat, OMC, Radius 2 82.00, B+ 1/4" UNC, Rotation CW, Bracket Hole Size 1 10.00, Holder Arm Width 50.50, D+ Size Plug, Belt Adjustment Bracket Hole Position 60, Total Length 170.00, Position 30, B+ Position 10
F032110641 - AlternatorTrade number 110641
Terminal W, Voltage 14, Amp 33, Grooves/pulley 1, Regulator type IR, Belt Adjustment Bracket Hole 1 8.00, Radius 86.00, Pulley Diameter 76.00, Prod. info BN, Pulley P, W plug type M5, Pulley Distance 76.50, Servicing Deutz, Fendt, Case, Claas, Goldoni, D+ Position 55, Radius 2 79.00, B+ M6, Rotation CW, Bracket Hole Size 1 8.00, Holder Arm Width 56.00, D+ Size M5, Belt Adjustment Bracket Hole Position 50, Total Length 162.00, Position 30, B+ Position 5
F032110881 - AlternatorTrade number 110881
Terminal W, Voltage 14, Amp 55, Grooves/pulley 2, Regulator type IR, Belt Adjustment Bracket Hole 1 8.20, Radius 83.00, Pulley Diameter 66.50, Prod. info BN, Pulley DP, W plug type M5-6.30, Pulley Distance 88.00, Servicing Volvo, D+ Position 58, Radius 2 80.00, B+ M6, Rotation CW, Bracket Hole Size 1 8.20, Holder Arm Width 56.00, D+ Size M5-6.30, Belt Adjustment Bracket Hole Position 50, Total Length 170.00, Position 40, B+ Position 20
F032110882 - AlternatorTrade number 110882
Voltage 14, Amp 45, Grooves/pulley 1, Regulator type IR, Belt Adjustment Bracket Hole 1 10.50, Mounting Bracket Distance 63.00, Radius 84.00, Pulley Diameter 71.30, Prod. info BN/OE, Bracket Hole Size Rear 12.00, Pulley P, Pulley Distance 47.00, Servicing Alfa Romeo, Fiat, Iveco, Lamborghini, Seat, Same, D+ Position 25, Fan EF, Radius 2 81.00, B+ M6, Rotation CW, Bracket Hole Size 1 12.20, Holder Arm Width 16.20, D+ Size 6.30, Belt Adjustment Bracket Hole Position 60, Total Length 181.50, Position 25, B+ Position 10, Remarks Connection 67 = D+ terminal.
